Specifications
Model Series
EHFA
Storage Capacity (L)
172
Hot Water Delivery (L)
160
Element Size (kW)
1.8, 2.4, 3.6
Total Height (mm)
1620
Width incl. PTR Valve (mm)
564
Diameter (mm)
500
Outlet Height (mm)
1419
Inlet Height (mm)
162
Electrical Entry – Lower (mm)
87
Electrical Entry – Upper (mm)
1039
Packaged Weight (kg)
60
Boost Capacity (Twin element only) (L)
40
Included PTR Valve (kPa)
1000
ECV (kPa)
850
Max. Inlet Pressure with ECV (kPa)
680
PLV with ECV (kPa)
500
Max. Inlet Pressure without ECV (kPa)
800
PLV without ECV (kPa)
500
Max. Thermostat Setting (°C)
70
Ingress Protection Rating
IPX4
Electrical Supply
240V – @50Hz
Hot and cold water connection
Rp 3/4 (20mm)
Tank Body Colour
Dune
