Specifications
Model Series
HFE
Storage Capacity (L)
33
Hot Water Delivery (L)
25
Element Size (kW)
1.8, 2.4, 3.6
Total Height (mm)
452
Width incl. PTR Valve (mm)
490
Diameter (mm)
415
Outlet Height (mm)
297
Inlet Height (mm)
153
Electrical Entry – Lower (mm)
80
Electrical Entry – Upper (mm)
N/A
Packaged Weight (kg)
23
Boost Capacity (Twin element only) (L)
N/A
Included PTR Valve (kPa)
1000
ECV (kPa)
850
Max. Inlet Pressure with ECV (kPa)
680
PLV with ECV (kPa)
500
Max. Inlet Pressure without ECV (kPa)
800
PLV without ECV (kPa)
500
Max. Thermostat Setting (°C)
70
Ingress Protection Rating
IPX4
Electrical Supply
240V – @50Hz
Hot and cold water connection
Rp 3/4 (20mm)
Tank Body Colour
White
